dataFEED OPC Suite Base

dataFEED OPC Suite Base

All-in-One solution for OPC UA communication and Big Data, IoT cloud connectivity

dataFEED OPC Suite Base is a software solution for OPC UA and OPC Classic communication and for cloud connectivity in a single product. Via the integrated OPC UA Server, it provides access to PLCs of all leading manufacturers such as Siemens SIMATIC S7, Rockwell ControlLogix, B&R, Mitsubishi and Modbus controllers (e.g. from Wago).

As a gateway between the two OPC standards, dataFEED OPC Suite also enables the integration of existing OPC Classic components and applications into modern Industrie 4.0 OPC UA solutions. Using the MQTT and REST protocols, production data can be transferred to IoT Cloud or Big Data applications on Microsoft Azure IoT, Amazon AWS, Google Cloud, Bosch PPM and Siemens MindSphere platforms. dataFEED OPC Suite also supports the storage of production data in a file, in an SQL database or in MongoDB and CouchDB.

Advantages:

  • Access to process and diagnostic data in controllers of leading manufacturers, including Siemens, Rockwell (Allen Bradley), B&R, Mitsubishi
  • Integration of legacy OPC Classic components and applications into modern Industry 4.0 OPC UA solutions
  • MQTT, MindConnect and REST gateway for integrating production data in IoT cloud and Big Data solutions, e.g. Microsoft Azure, Amazon AWS and Siemens MindSphere

Download Free Demo Version





Product details

Category: Gateway Subcategory: Protocol Converter

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Standard 2017 UA Server Profile

Security Policies:

  • UACore 1.04
    • SecurityPolicy - Aes256-Sha256-RsaPss
    • SecurityPolicy [A] - Aes128-Sha256-RsaOaep
    • SecurityPolicy [B] – Basic256Sha256
    • SecurityPolicy – Basic128Rsa15
    • SecurityPolicy – Basic256
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Facet
    • User Token – Anonymous Server Facet
    • User Token – User Name Password Server Facet
    • User Token – X509 Certificate Server Facet

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Standard UA Client 2017 Profile

Security Policies:

  • UACore 1.04
    • SecurityPolicy - Aes256-Sha256-RsaPss
    • SecurityPolicy [A] - Aes128-Sha256-RsaOaep
    • SecurityPolicy [B] – Basic256Sha256
    • SecurityPolicy – Basic128Rsa15
    • SecurityPolicy – Basic256
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Client Facet
    • User Token – Anonymous Facet
    • User Token – User Name Password Client Facet
    • User Token – X509 Certificate Client Facet
  • Data Access 2.05a
  • Data Access 3.0
  • Data Access 2.05a
  • Data Access 3.0
