DeviceXPlorer OPC Server

DeviceXPlorer OPC Server

DeviceXPlorer OPC Server is compatible with OPC UA(Unified Architecture) and OPC DA, OPC AE for each controllers.  We regard high performance and easy operation. So it provides high-end programming and much easier operation than before.  We adopt wizard and user interface for easy operation and comfortable work. We try to produce software to gain every user’s satisfaction.

The latest series called DxpSERVER series of DeviceXPlorer OPC Server provide you connectivity for over 400 devices such as PLC, robot, NC, insturuments.  Also it has many robust features, such as native 64-bit application and latest user interface included PropertyPage or multiple-language, IPv6, script, structured-tag, dynamic-configuration and so on.

We believe that DeviceXPlorer will be key component for your smart factory.

Compatible Device Vendors

  • Mitsubishi MELSEC
  • Omron SYSMAC
  • Yokogawa FA-M3
  • Jtekt TOYOPUC
  • Hitachi HIDIC
  • Sharp SATELLITE
  • Fuji MICREX
  • Panasonic FP
  • Keyence KV
  • Toshiba V
  • Kawasaki RCC
  • YASKAWA Robot simulator
  • YAMAHA Robot Controller
  • IAI Program Controller
  • Azbil
  • Mitsubishi CNC/EDM
  • Fanuc PMC
  • ShibauraMachine TOSNUC
  • Rockwell ControlLogix
  • Siemens Simatic
  • GE
  • Cognex Dataman/Insight
  • Delta
  • Lsis
  • Koyo
  • Idec
  • 3S
  • Yasukawa MP
  • M-System R3
  • Anywire
  • Wago
  • Mars Tohken Solution
  • Hakko Monitouch
  • Eurotherm
  • RKC Instrument
  • Chino
  • Hioki Smartsite
  • Unitec
  • MTT
  • PHOENIX CONTACT
  • silex technology
  • SANYO DENKI
  • Modbus
  • EtherNet/IP
  • BACnet
  • IEC60870
  • IEC61850
  • DNP3
  • SLMP
  • MTCONNECT
  • OPCDA
  • OPCUA
  • DDE
  • ODBC





Product details

Category: Gateway Subcategory: Protocol Converter

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Standard 2017 UA Server Profile

Additional Facets:

  • UACore 1.04
    • Base Server Behaviour Facet
    • Core 2017 Server Facet
    • PubSub UDP UADP
    • UA-TCP UA-SC UA-Binary

Security Policies:

  • UACore 1.04
    • SecurityPolicy - Aes256-Sha256-RsaPss
    • SecurityPolicy [A] - Aes128-Sha256-RsaOaep
    • SecurityPolicy [B] – Basic256Sha256
    • SecurityPolicy – Basic128Rsa15
    • SecurityPolicy – Basic256
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Facet
    • User Token – Anonymous Server Facet
    • User Token – User Name Password Server Facet
    • User Token – X509 Certificate Server Facet

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Standard UA Client 2017 Profile

Additional Facets:

  • UACore 1.04
    • Attribute Read Client Facet
    • Attribute Write Client Facet
    • Base Client Behaviour Facet
    • Core 2017 Client Facet
    • UA-TCP UA-SC UA-Binary

Security Policies:

  • UACore 1.04
    • SecurityPolicy - Aes256-Sha256-RsaPss
    • SecurityPolicy [A] - Aes128-Sha256-RsaOaep
    • SecurityPolicy [B] – Basic256Sha256
    • SecurityPolicy – Basic128Rsa15
    • SecurityPolicy – Basic256
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Client Facet
    • User Token – Anonymous Facet
    • User Token – User Name Password Client Facet

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Publisher UDP UADP Dynamic Profile

Security Policies:

  • UACore 1.04
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Facet

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Subscriber UDP UADP Dynamic Profile

Security Policies:

  • UACore 1.04
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Facet
  • Data Access 2.05a
  • Data Access 3.0
  • Alarms and Events
  • Data Access 2.05a
  • Data Access 3.0

Product certification history

Certified Profiles Standard UA Server
Certificate Number 2102CE00D3
Certification Date 02/12/2021
Expiration Date 02/29/2024
CTT Version 1.03.341.396
Additional Facets Method Server Facet
Security Policies SecurityPolicy - Basic128Rsa15,
SecurityPolicy - Basic256,
SecurityPolicy - Basic256Sha256,
SecurityPolicy - Aes128_Sha256_RsaOaep,
SecurityPolicy - Aes256_Sha256_RsaOaep
User Identity Tokens User Token - Anonymous Facet,
User Token - User Name Password Server Facet,
User Token - X509 Certificate
Product Name DeviceXPlorer OPC Server
Certified Product Version 6.1.0
Product MD5 Hash 607f9a2a92bacc98540fa3f348883518
Standard UA Server
Certified Profiles Data Access 2.05a
Data Access 3.0
Certificate Number 1308CS0040
Certification Date 08/06/2013
Expiration Date 08/31/2016
CTT Version DA 3.0 1.00.16.1156; DA 2.05a 2.00.20.1156
Product Name Device Xplorer OPC Server
Certified Product Version 5.0.5
Data Access 2.05a<br>Data Access 3.0
